Very easy installation saves a lot of time. Only the power supply needs to be connected.
No cables from the monitor to the camera needed.
No additional cable connections needed when connecting a trailer.
No interference due to digital video transmission.
Integrated microphone.
Integrated heater to prevent fog and snow on the lens.
Easy pairing by one push button.
| Resolution | 1920x1080 | |||
| Megapixel | 2 MP | |||
| Video Format | 1080p | |||
| Sensor Type | CMOS | |||
| Sensor Manufacturer | GalaxyCore | |||
| Sensor Size | 1/2.9 inch | |||
| Sensing Area | 5.59 mm x 3.1 mm | |||
| Pixel Size | 2.8 µm x 2.8µm | |||
| Frame Rate | 25 fps | 30 fps | ||
| Scanning System | Progressive Scan | |||
| Shutter Mode | Rolling Shutter | |||
| S/N Ratio | >52 dB | |||
| Dynamic Range | 81dB | |||
| AWB | Auto | |||
| AGC | Auto | |||
| BLC | Auto | |||
| Frequency Range | 2403MHz-2478MHz | |||
| max. Range (Barrier Free) | FCC: 300 m | CE: 200 m | MIC: 100 m | |
| Transmission Power | FCC: ≤26dBm | CE: ≤20dBm | MIC: ≤10dBm | |
| Receiving Sensitivity | -78dBm | |||
| Video Codec | H.264 | |||
| RF Bit Rate | max. 12 Mbps | |||
| Modulation | FHSS | |||
| Delay | max. 200 ms | |||
| Focal Length | 2.8 mm | |||
| Aperture | f / 2.3 | |||
| Focus | Fixed | |||
| Field of View (FOV) | 120°(D) x 105°(H) x 60°(V) | |||
| Operating Voltage | 10-32 VDC | |||
| Current @12 VDC | Normal: 185 mA, IR: +100 mA | |||
| Power Consumption | max. 3.5 W | |||
| Operating Temperature | -30°C - +70°C | |||
| Storage Temperature | -40°C - +80°C | |||
| IR-LED | Yes | |||
| IR Wavelength | 850 nm | |||
| Night Vision Distance | 10 – 15 m | |||
| IR-Cut | Dual Filter Switch ( Auto) | |||
| Minimum Illumination | 0 Lux | |||
| Audio | Yes | |||
| Heater | No | |||
| Image Mode | Mirror | |||
| Dimensions | 109.2 mm x 95.7 mm x 72.1 mm (with Bracket and Sun Shield) | |||
| Weight | 450g | |||
| IP Protection Class | IP69K | |||
| Vibration Resistant | 5.9 G | |||
| Shock Resistant | 10 G | |||
| Material | Aluminum, Glass, Stainless Steel | |||
| Color | Black | |||
| Cable Length | 30 cm | |||
| Cable Diameter | 5.0 mm | |||
| min. Bending Radius | 5 x Cable Diameter | |||
| Connector Type | Barrel Connector (5.5 mm / 2.1 mm) incl. Adapter with open ends | |||
| Connector Diameter | 14 mm | |||
